Specifications
| Motor | Yanmar Model L100N6, 10HP, Straight Shaft, Recoil Start |
|---|---|
| Pump | Mazzoni Model MMD-CW 15250, 15L/Min, 3000psi, 1450rpm |
| Drive | Direct via Hollow Shaft PA B24 2:1 Gear Box |
| Base | Galvanised Large Roll Frame, 4 Pneumatic 10″ Wheels |
| Inlet | Direct via Inline Filter |
| Outlet | Via K1 Automatic Unloader Valve and Wika Pressure Gauge |
| Hose | 10mt 3/8″ Double Braided, High Pressure With Quick Connect Ends |
| Gun | With 1.1mt S.S Single Lance and Fan Jet 050 |
| Weight | 43 kg |
| Dimensions | 103 × 72 × 78 cm |
Documentation
More Information
- Painted steel frame
- Asynchronous electric motor
- Mazzoni bypass valve
- TST Total Stop
- SMS Safe Manometer System
- Internal hour meter
- Detergent suction in low pressure
- Turbo nozzle
- Full range of Accessories
