SPECIFICATIONS
Motor |
Nicolini Three Phase 20HP, 28.9A |
---|---|
Pump |
Mazzoni Model GM-CW 22300, 22L/Min, 4350psi, 1450rpm |
Drive |
Direct via Double Flange Motor With Flexible Coupling |
Flow Rate |
15L/Min |
Max Pressure |
3600psi |
Revolutions |
1450rpm |
Voltage |
400V |
Max Power |
10hp |
Ampere |
16A |
Base |
Galvanised Large Roll Frame, 4 Pneumatic 10" Wheels |
Inlet |
Direct via Inline Filter |
Outlet |
Via VHP39 Unloader Valve and Wika Pressure Gauge |
Switch |
Three Phase with Thermo Overload, 3Mt Lead and 32A Plug |
Hose |
10mt 3/8" Double Braided, High Pressure With Quick Connect Ends |
Gun |
With 1.1mt S.S Single Lance and Fan Jet 055 |
Weight | 156 kg |
Dimensions | 103 × 71.5 × 78 cm |
